PEAK SURGICALS

Small Fragment Instruments Set

Small Fragment Instruments Set

PS-OP-0486

$768.90 USD
$768.90 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Secure Checkout Protected payment flow
Quality Inspected Checked before dispatch
Worldwide Supply International buyer support
Shipping, Returns & Payments Clear buyer information before checkout.
Shipping
Free shipping on orders over $99. See shipping details
Returns
Returns and exchanges are handled according to our return policy. See return policy
Payments
American Express Apple Pay Diners Club Discover Google Pay JCB Mastercard
Return / Exchange Info
View full details

The Small Fragment Instruments Set by Peak Surgicals is a comprehensive orthopedic instrumentation set configured for small-fragment plate and screw fixation workflows. It combines drilling, tapping, screw measurement, reduction, plate bending, screw insertion, and bone-handling instruments in one organized set.

The set includes dedicated instrumentation for 3.5mm cortex screws and 4.0mm cancellous screws, along with 2.5mm and 3.2mm drill components, depth measurement instruments, reduction forceps, periosteal elevators, and a screw rack container for organized storage.

Set Contents

Set Consisting of : Units
PS.011.01 - Neutral & Loaded Drill Guide Ø 2.5 1
PS.011.02 - Drill & Tap Guide (Ø 2.5/ Ø 3.5) 1
PS.011.03 - Drill & Tap Guide (Ø 3.2/ Ø 4.0) 1
PS.011.04 - Drill Bit Ø 2.5 x 115mm 2
PS.011.05 - Drill Bit Ø 3.2 x 115mm 2
PS.011.06 - ObliPSue Reduction Forcep 170mm 1
PS.011.07 - Bending Iron 2
PS.011.08 - Periosteal Elevator 6mm 1
PS.011.09 - Tap for 4.0mm Cancellous Screw 1
PS.011.10 - Depth Gauge (0-60mm) 1
PS.011.11 - Countersink 6mm 1
PS.011.12 - Extraction Screw Hexagonal 2.5mm Conical 1
PS.011.13 - Periosteal Elevator 12mm 1
PS.011.14 - Hollow Mill Reamer Ø 6.0 1
PS.011.15 - Tap for 3.5mm Cortex Screw 1
PS.011.16 - Hexagonal Screwdriver 2.5mm (Silicon Handle) 1
PS.011.17 - Self Centering Bone Holding Forcep 190mm 2
PS.011.18 - Sharp Reduction Forcep 190mm 1
PS.011.19 - PSuick Coupling Handle (T-Type) 1
PS.011.000 - Empty Container with Screw Rack

Key Features

  • Small Fragment Fixation Instrumentation: Combines essential instruments for drilling, tapping, measurement, reduction, and screw insertion during orthopedic fixation workflows.
  • 3.5mm Cortex Screw Instrumentation: Includes a dedicated tap and compatible drill-and-tap guide for 3.5mm cortex screw preparation.
  • 4.0mm Cancellous Screw Instrumentation: Includes a dedicated tap together with supporting drill-and-tap instrumentation.
  • Drilling Components: Includes 2.5mm and 3.2mm drill bits, neutral and loaded drill guide, and dedicated drill-and-tap guides.
  • Reduction & Bone Handling: Includes self-centering bone holding forceps, sharp reduction forceps, periosteal elevators, and bending irons.
  • Measurement & Screw Handling: Includes a 0-60mm depth gauge, countersink, extraction screw, 2.5mm hexagonal screwdriver, and T-type quick coupling handle.
  • Organized Storage: Supplied with an empty container and screw rack for systematic organization of the instruments.

Applications

The Small Fragment Instruments Set is configured for orthopedic small-fragment fixation workflows requiring drilling, tapping, fracture reduction, plate preparation, depth measurement, and screw insertion instrumentation.

It is suitable for orthopedic departments, trauma centers, hospitals, surgical facilities, and medical procurement professionals sourcing a coordinated small-fragment orthopedic instrument set.

Refer to the Set Contents table above for exact catalog numbers, instrument dimensions, and supplied quantities.
