Cortex Screw Ø 2.4mm – Stainless Steel & Titanium

Cortex Screw Ø 2.4mm – Stainless Steel & Titanium

The Cortex Screw Ø 2.4mm is an orthopedic fixation screw available in both stainless steel and titanium configurations. The current Peak Surgicals range provides multiple lengths from 6 mm to 20 mm, allowing orthopedic teams and procurement departments to select the required screw according to the implant system and fixation requirements.

The main Peak Surgicals product is identified as SKU PS-OP-02405. Separate catalog codes are provided for stainless steel and titanium versions across the available lengths, making material and length important purchasing identifiers for this 2.4 mm cortex screw range.

2.4mm Cortex Screw Configuration

The screw has a confirmed nominal diameter of Ø 2.4 mm. This diameter forms the primary product designation and should be referenced together with the required length and material when selecting the correct variant.

The current product page does not state the thread pitch, core diameter, head dimensions, drive configuration, or exact screw-system compatibility. These technical specifications should therefore be confirmed when required for a particular orthopedic implant system.

Stainless Steel and Titanium Options

The live Peak Surgicals specification table lists both stainless steel and titanium versions of the Cortex Screw Ø 2.4mm.

Each length has a separate stainless-steel catalog code and titanium catalog code. Buyers should therefore specify both the required material and length when placing an order.

Available Length Range

The current product range includes 11 confirmed screw lengths: 6 mm, 7 mm, 8 mm, 9 mm, 10 mm, 11 mm, 12 mm, 14 mm, 16 mm, 18 mm, and 20 mm.

The live page does not list a 13 mm, 15 mm, 17 mm, or 19 mm option, so those sizes should not be assumed to be available within this specific product range.

6mm to 9mm Cortex Screw Options

The shorter configurations include 6 mm, 7 mm, 8 mm, and 9 mm lengths. Stainless-steel catalog numbers are 118.206, 118.207, 118.208, and 118.209 respectively, while the corresponding titanium versions use PS-118.206, PS-118.207, PS-118.208, and PS-118.209.

10mm to 12mm Cortex Screw Options

The mid-range options include 10 mm, 11 mm, and 12 mm. Stainless-steel versions are identified as 118.210, 118.211, and 118.212, with corresponding titanium catalog codes PS-118.210, PS-118.211, and PS-118.212.

14mm to 20mm Cortex Screw Options

The longer listed configurations are 14 mm, 16 mm, 18 mm, and 20 mm. Stainless-steel catalog codes are 118.214, 118.216, 118.218, and 118.220, while titanium versions are PS-118.214, PS-118.216, PS-118.218, and PS-118.220.

Orthopedic Fixation Application

The Cortex Screw Ø 2.4mm is positioned within Peak Surgicals' orthopedic plate-and-screw range. Cortex screws are selected within orthopedic fixation systems when a compatible 2.4 mm cortical screw configuration is required.

The exact plate system, screw-hole compatibility, drilling protocol, insertion technique, and required length should be determined according to the specific implant system and surgical plan.

Material and Length Selection

The live storefront provides separate Material and Size selectors. Buyers should confirm both fields before ordering because the catalog code changes according to the selected material and length.

Using the exact catalog number is especially useful for hospitals, orthopedic distributors, and implant procurement teams managing multiple screw lengths within the same 2.4 mm diameter system.

Product Specifications

Product Name	Cortex Screw Ø 2.4mm
Main SKU	PS-OP-02405
Product Type	Orthopedic Cortex Screw
Nominal Diameter	Ø 2.4 mm
Material Options	Stainless Steel / Titanium
6 mm	SS: 118.206 / Titanium: PS-118.206
7 mm	SS: 118.207 / Titanium: PS-118.207
8 mm	SS: 118.208 / Titanium: PS-118.208
9 mm	SS: 118.209 / Titanium: PS-118.209
10 mm	SS: 118.210 / Titanium: PS-118.210
11 mm	SS: 118.211 / Titanium: PS-118.211
12 mm	SS: 118.212 / Titanium: PS-118.212
14 mm	SS: 118.214 / Titanium: PS-118.214
16 mm	SS: 118.216 / Titanium: PS-118.216
18 mm	SS: 118.218 / Titanium: PS-118.218
20 mm	SS: 118.220 / Titanium: PS-118.220
Self-Tapping	Not Specified for This Product Page
Thread Pitch / Head Design	Not Specified on Current Product Page

For Orthopedic Hospitals and Implant Procurement

The Cortex Screw Ø 2.4mm range is relevant for orthopedic hospitals, trauma and hand surgery departments, implant distributors, surgical centers, and procurement teams sourcing small-diameter orthopedic fixation screws.

For accurate purchasing, buyers should reference SKU PS-OP-02405 together with the required material, screw length, and corresponding catalog code. Buyers requiring exact thread pitch, head profile, drive type, screw-system compatibility, titanium or stainless-steel alloy grade, or sterility status should confirm those specifications before ordering because they are not stated on the current product page.

Frequently Asked Questions

What diameter is this Cortex Screw?

The current Peak Surgicals product is identified as a Ø 2.4 mm Cortex Screw.

Which materials are available?

The live specification table lists both stainless steel and titanium configurations.

Which lengths are available?

The confirmed lengths are 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, and 20 mm.

What is the main SKU?

The current Peak Surgicals storefront SKU is PS-OP-02405.

Is this Cortex Screw self-tapping?

The current product page does not identify this specific Cortex Screw Ø 2.4mm as self-tapping. Peak Surgicals has separately listed self-tapping screw products, so this feature should not be assumed for PS-OP-02405.

Do stainless steel and titanium versions use different codes?

Yes. For example, the 10 mm stainless-steel version is 118.210, while the 10 mm titanium version is PS-118.210.
