The Carbon Fiber 1 or 2 Ring Pediatric is an orthopedic external fixation component designed for pediatric fixation systems. The product is manufactured in multiple ring dimensions to accommodate different external fixation configurations and is part of the Peak Surgicals External Fixators range. The product page provides four defined dimensional combinations with inner diameters ranging from 80mm to 120mm and corresponding outer diameters from 112mm to 152mm.
The ring configurations are differentiated by inner diameter, outer diameter, number of holes, and individual half-ring reference codes. These dimensional options allow orthopedic teams and procurement departments to identify the required ring size accurately when assembling or replacing components within a pediatric external fixation system.
The product uses a carbon fiber ring design intended for orthopedic external fixation applications. The pediatric range is offered in several diameters so that different frame dimensions can be selected according to the fixation setup being used. Each listed option has a specified inner diameter and outer diameter, providing a clear dimensional reference when selecting the ring.
The ring also incorporates multiple holes around its structure. The number of holes varies according to the selected size. The 80mm inner diameter configuration has 13 holes, the 90mm version has 14 holes, the 100mm configuration has 17 holes, and the 120mm version has 19 holes. These hole counts are part of the individual product specifications and distinguish the four listed configurations.
Each dimensional option is also associated with a dedicated half-ring reference. These references allow the correct component to be identified when ordering or maintaining inventory. Because the dimensions and hole counts differ between configurations, the complete size and reference should be checked before purchase.
The pediatric carbon fiber ring is available in four documented dimensional combinations. The smallest listed configuration has an 80mm inner diameter and 112mm outer diameter, while the largest has a 120mm inner diameter and 152mm outer diameter. Intermediate options of 90mm inner diameter with 122mm outer diameter and 100mm inner diameter with 132mm outer diameter are also provided.
The complete dimensional combination should be used when selecting a ring because the inner diameter, outer diameter, and number of holes change together. This is especially important for hospitals, orthopedic departments, distributors, and procurement teams managing external fixation components.
This pediatric carbon fiber ring belongs to the external fixation instrument and component range. External fixation systems use rings and related connecting components to create an orthopedic frame outside the body. The exact frame arrangement, number of rings, and ring dimensions are determined by the orthopedic surgeon according to the fixation system and surgical plan.
The different pediatric dimensions allow the ring component to be selected according to the required external fixation frame size. The product should be used by trained orthopedic professionals familiar with the external fixation system being assembled. Selection should be based on the complete dimensional information rather than the product family name alone.
| Product Name | Carbon Fiber 1 or 2 Ring Pediatric |
|---|---|
| SKU | PS-OP-5955 |
| Product Type | Pediatric External Fixator Ring |
| Material | Carbon Fiber |
| Configuration 1 | 80mm ID × 112mm OD, 13 Holes, Half Ring PS180.80-112 |
| Configuration 2 | 90mm ID × 122mm OD, 14 Holes, Half Ring PS180.90-122 |
| Configuration 3 | 100mm ID × 132mm OD, 17 Holes, Half Ring PS180.100-132 |
| Configuration 4 | 120mm ID × 152mm OD, 19 Holes, Half Ring PS180.120-152 |
| Product Price | From $55.00 USD |
| Category | Orthopedic External Fixators |
| Brand | Peak Surgicals |
The ring should be handled and maintained according to the instructions associated with the external fixation system and the healthcare facility's established procedures. Before use, inspect the component for visible damage, deformation, cracks, or other defects that could affect its condition. Particular attention should be given to the ring body and the holes used within the fixation assembly.
Cleaning, preparation, storage, and any required processing should follow product-specific instructions and institutional protocols. Generic sterilization temperatures, exposure times, or processing cycles should not be used in place of verified instructions for the product.
When ordering the Carbon Fiber 1 or 2 Ring Pediatric, confirm the required inner diameter, outer diameter, hole count, and half-ring reference. The four documented configurations are 80/112mm with 13 holes, 90/122mm with 14 holes, 100/132mm with 17 holes, and 120/152mm with 19 holes.
For related fixation components, explore the External Fixators collection.
It is an orthopedic ring component used within pediatric external fixation systems.
The documented inner diameter options are 80mm, 90mm, 100mm, and 120mm.
The corresponding outer diameters are 112mm, 122mm, 132mm, and 152mm.
The four configurations have 13, 14, 17, and 19 holes respectively.
The product SKU is PS-OP-5955.
The product is currently priced from $55.00 USD.
